Cách Hoạt Động Của Lưu Lượng Kế Siêu Âm
How Ultrasonic Flowmeters Work
Lưu lượng kế siêu âm sử dụng sóng âm để xác định vận tốc chất lỏng chảy trong ống.
Ultrasonic flowmeters use sound waves to determine the velocity of a fluid flowing in a pipe.
- Hiệu ứng Doppler: Khi không có dòng chảy, tần số sóng siêu âm truyền và phản xạ từ chất lỏng là như nhau. Khi có dòng chảy, tần số phản xạ thay đổi do hiệu ứng Doppler.Doppler Effect: At no flow conditions, the frequencies of transmitted and reflected ultrasonic waves are the same. Under flow conditions, the frequency of the reflected wave changes due to the Doppler effect.
- Thời gian truyền (Transit Time): Lưu lượng kế siêu âm thời gian truyền gửi và nhận sóng siêu âm theo hướng xuôi và ngược dòng. Khi dòng chảy, sóng xuôi dòng di chuyển nhanh hơn so với sóng ngược dòng.Transit Time: Transit time ultrasonic flowmeters send and receive ultrasonic waves upstream and downstream. During flow, the downstream wave travels faster than the upstream wave.
Ưu Điểm Và Nhược Điểm
Plusses and Minuses
Ưu điểm / Advantages:
- Độ chính xác cao, áp dụng trong đo lường thương mại như dâu khí và chất lỏng dầu mỏ.
Highly accurate, suitable for custody transfer applications like natural gas and petroleum liquids. - Phạm vi đo rộng, đo được lưu lượng rất nhỏ.
Wide turndown, capable of measuring very low flow rates. - Hoạt động ở áp suất và nhiệt độ cao.
Handles high pressure and extreme temperatures. - Dễ dàng lắp đặt bên ngoài ống mà không gây cản trở dòng chảy.
Clamp-on installation avoids penetration into the pipe.
Nhược điểm / Disadvantages:
- Chi phí cao.
High cost. - Nhạy cảm với rung động từ quy trình.
Sensitive to stray vibrations. - Độ chính xác của loại kẹp ngoài thấp hơn.
Clamp-on transducers have lower accuracy.
Ứng Dụng Của Lưu Lượng Kế Siêu Âm
Applications of Ultrasonic Flowmeters
- Phù hợp cho các chất lỏng vệ sinh, chống ăn mòn và mài mòn.
Ideal for sanitary, corrosive, and abrasive liquids. - Loại kẹp ngoài phù hợp khi không thể thay đổi ống dẫn, đặc biệt trong ngành năng lượng và hạt nhân.
Clamp-on transducers are useful in power and nuclear industries where piping cannot be disturbed. - Thích hợp đo dòng chảy tạm thời.
Portable ultrasonic flowmeters are ideal for temporary flow measurements.
Ngành Được Ứng Dụng
Industries Where Used
Thứ tự từ cao đến thấp: Dầu khí, nước và nước thải, năng lượng, hóa chất, thực phẩm và đồ uống, dược phẩm, kim loại và khai khoáng, bột giấy và giấy.
From highest to lowest: Oil & gas, water & wastewater, power, chemicals, food & beverage, pharmaceuticals, metals & mining, pulp & paper.
Kích Thước Và Ứng Dụng / Sizes and Applications
– Kích thước: Có thể sản xuất lên đến 72 inch hoặc lớn hơn.
– Ứng dụng: Sử dụng để đo dòng chảy của nước, chất lỏng đông lạnh và hóa chất.
Lưu Ý Khi Sử Dụng
Application Cautions
- Lưu lượng kế siêu âm thời gian truyền (Transit Time):
- Đảm bảo chất lỏng có khả năng truyền dẫn sóng siêu âm. Nếu sóng siêu âm không thể xuyên qua luồng chất lỏng, lưu lượng kế sẽ không đo được.
- Tránh sử dụng với chất lỏng mờ đục hoặc có nhiều tạp chất làm yếu tín hiệu sóng, điều này gây sai số hoặc làm lưu lượng kế ngừng hoạt động.
Transit Time Ultrasonic Flowmeters:
- Ensure the fluid adequately conducts ultrasonic waves. If waves cannot penetrate the fluid stream, the flowmeter cannot measure.
- Avoid using with opaque or highly contaminated fluids that weaken ultrasonic signals, leading to inaccuracies or device failure.
- Lưu lượng kế siêu âm Doppler (Doppler Ultrasonic Flowmeters):
- Đảm bảo chất lỏng có khả năng phản xạ sóng siêu âm, như bọt khí nhỏ hoặc xoáy trong luồng chất lỏng.
- Đặc biệt cẩn tránh các ứng dụng có nhiều tạp chất làm lưu lượng kế đo sai vận tốc chất rắn thay vì vận tốc chất lỏng.
Doppler Ultrasonic Flowmeters:
- Ensure the fluid reflects ultrasonic waves effectively, such as through small gas bubbles or eddies.
- Be cautious in applications with solid particles or slurry, as the device may measure the velocity of solids instead of the liquid.
- Cần tránh chất lỏng bám bẩn:
- Các chất lỏng có thể bám bẩn trên đầu dò hoặc bên trong ống có thể làm yếu sóng siêu âm, làm lưu lượng kế không đo được.
- Đảm bảo đầu dò kẹp ngoài kết nối chắc chắn với ống dẫn.
Avoid fouling fluids:
- Fluids that coat transducers or pipe walls can weaken ultrasonic waves, causing the flowmeter to fail.
- Ensure reliable connections for clamp-on transducers to maintain accurate measurements.
- Quy trình vệ sinh:
- Quá trình làm sạch hoặc bụi bẩn tống hợp trước đó có thể gây giản hiệu sóng siêu âm, làm ngừng hoạt động thiết bị.
- Khi đầu dò bị bám bẩn, cần được làm sạch trước khi sử dụng lại.
Cleaning Process:
- Cleaning or upstream dirt buildup can weaken signals and stop flowmeter operation.
- Transducers should be cleaned if fouled before resuming operation.
